Condition: New Open Box

Main Features

Slot
Switch
L3
managed
44 x 10/100/1000 4 x combo Gigabit SFP
front to back airflow
rack-mountable

The Aruba 2930M Switch Series is designed for digital workplaces optimized for mobile users. These Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager, Aruba AirWave and cloud-based Aruba Central. Modular stacking, uplinks and power provide scalability and simplicity for enterprise edge, SMB and branch offices. The 2930M delivers performance and value with support for static, RIP and Access OSPF routing, 10GbE and 40GbE uplinks, models with 24 ports of HPE Smart Rate multi-gigabit Ethernet, up to 1440W of PoE , robust QoS, SDN and requires no software licensing.

Tech Specs

Specifications are provided by the manufacturer.

· Header

Manufacturer : Aruba
Brand : Aruba
Product Line : HPE Aruba
Model : 2930M 48G 1-Slot
Packaged Quantity : 1

· Chassis

Airflow Direction : Front to back airflow

· Processor

Type : Cortex-A9
Installed Qty : 1
Manufacturer : ARM
Clock Speed : 1.016 GHZ

· RAM

Technology : DDR3 SDRAM
Installed Size : 1 GB

· Flash Memory

Installed Size : 4 GB, 4 GB

· Performance

Performance : Latency (1 Gbps): 3.1 µs, Latency (10 Gbps): 3.4 µs, Latency (10 Mbps): 98.5 µs, Latency (100 Mbps): 11.8 µs, Stacking bandwidth: 100 Gbps, Switching capacity: 176 Gbps, Throughput: 112 Mpps

· Capacity

Capacity : IPv4 routing table entries: 2000, IPv6 routing table entries: 1000, OSPF routes: 200, RIP routes: 10000, Static routes: 256

· Networking

Type : Switch
Subcategory : Network hubs and switches
Subtype : Gigabit Ethernet
Form Factor : Rack-mountable
Stackable : Stackable
Ports Qty : 48
Advanced Switching : Layer 3
Routing Protocol : CIDR, IGMP, IGMPv2, IGMPv3, MLD, MLDv2, OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2, RIPng, Static IP routing, Static IPv4 routing, Static IPv6 routing
MAC Address Table Size : 32768 entries
Jumbo Frame Support : 9220 bytes
Manageable : Yes
Remote Management Protocol : CLI, HTTP, RMON, RMON 1, RMON 2, RMON 3, RMON 9, SNMP, SNMP 1, SNMP 2, SNMP 2c, SNMP 3, SSH, SSH-2, Telnet, XRMON
Features : BOOTP support, Class of Service (CoS), DHCP protection, DHCP server, DHCP support, DiffServ support, Dynamic ARP protection, Dynamic VLAN Support (GVRP), Flow control, Front to back airflow, ICMP Router Discovery Protocol (IRDP), IGMP snooping, IPv6 support, Management Information Base (MIB), Multiple VLAN Registration Protocol (MVRP), Quality of Service (QoS), sFlow, SNTP support, STP Root Guard, Type of Service (ToS), Uni-Directional Link Detection (UDLD), Virtual Extensible LAN (VXLAN), VLAN support
Compliant Standards : IEEE 802.1ab (LLDP), IEEE 802.1ad, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3az, IEEE 802.3x

· Ports

Qty : 44
Type : 10/100/1000

· Ports (2nd)

Qty : 4
Type : Combo Gigabit SFP

· Expansion Slots

Expansion Slots : 1 (total) / 1 (free) x expansion slot, 1 (total) / 1 (free) x Stacking Module slot

· Interface Provided

Interfaces : 1 x management RJ-45, 1 x serial (console) RJ-45, 1 x USB Type B, 4 x Gigabit LAN, 44 x 1000Base-T RJ-45

· Power Device

Type : Internal power supply, Internal power supply (not installed)
Installed Qty : 0
Max Supported Qty : 2
Nominal Voltage : AC 120/230 V
Frequency Required : 50/60 hertz
80 PLUS Certification : 80 PLUS Silver

· Miscellaneous

Color Category : Black
Height (Rack Units) : 1
Encryption Algorithm : MD5, SSL
Authentication Method : CHAP, PAP, RADIUS, TACACS, TACACS
Compliant Standards : CISPR 22 Class A, CISPR 24, CNS 13438, CSA C22.2 No. 60950-1-07 Second Edition, EN 55022:2010, EN 55024:2010, EN 60825-1:2007, EN 60950-1:2006 A11:2009 A1:2010 A12:2011 A2:2013, EN 60950-1:2006 A11:2009 A1:2010 A12:2011 A2:2013, FCC CFR47 Part 15 A, ICES-003 Class A, IEC 60825-1:2007, IEC 60950-1:2005 A1:2009 A2:2013, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC60950-1:2005 A1:2009 A2:2013, UL 60950-1 Second Edition, VCCI Class A
