Product Details

Product Description

  • The GWN7803 series are Layer 2 managed network switches that allow small-to-medium enterprises to build scalable, secure, high performance, and smart business networks that are fully manageable

  • It supports advanced VLAN for flexible and sophisticated traffic segmentation, advanced QoS for prioritization of network traffic, IGMP Snooping for network performance optimization, and comprehensive security capabilities against potential attacks

  • The PoE models provide smart dynamic PoE output to power IP phones, IP cameras, Wi-Fi access points and other PoE endpoints

  • The GWN7803 series can be managed in a number of ways, including the local web user interface of the GWN7803 series switch

  • The series is also supported by GWN

  • Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform

  • The enterprise-grade GWN7803 series are the ideal managed network switches for small-to-medium businesses

Product Specification

Brand

Grandstream

Product Type

Network Switch

Product Model

GWN7803

Gigabit Ethernet Ports

24

Network Protocols

IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1d, IEEE
802.1s

Integrated Power Supply

30 W

Auxiliary Ports

1x Reset Pinhole

Forwarding Mode

Store-and-forward

Total Non-Blocking Throughput

28Gbps

Switching Capability

56Gbps

Forwarding Rate

41.66Mpps

Packet Buffer

4.1Mb

Network Latency

Avg<4μs

Switching


8K static, dynamic and filtering MAC addresses
4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN
VLAN virtual interface
GVRP (pending)
8 link aggregation groups
Spanning tree, 16 instances for STP/RSTP/MSTP

Multicast

IGMP Snooping, MLD Snooping, MVR

QoS/ACL

Auto detection and prioritization of voice/video/RTP/SIP/other latency-sensitive packets (pending)
Port priority
Priority mapping
Queue scheduling, including SP, WRR, WFQ, SP-WRR and SP-WFQ
Traffic shaping
Rate limit
1.5K ACL for Ethernet, IPv4 and Ipv6

DHCP

DHCP server, DHCP relay, Option 82, 60,160 and 43

Maintenance

CPU and memory monitoring, SNMP, RMON, LLDP&LLDP-MED, backup and restore, syslog, alert, diagnostics including Ping, Traceroute, port
mirroring, UDLD(TBD) and copper test

Security

User hierarchical management and password protection, HTTPS, SSH, Telnet
802.1X authentication
AAA authentication including RADIUS, TACACS
Storm control
Port isolation, port security, sticky MAC
Filtering MAC address
IP source guard, DoS attack prevention, ARP inspection
DHCP Snooping
Loop protection including BPDU protection, root protection and loopback protection
Kensington Security Slot (Kensington Lock) support

LEDs

1x tri-color LED for
device tracking and
status indication,
28x green LEDs for
data ports

Environmental

Operation: 0°Cto 45°C, humidity 10-90% RH(Non-condensing)
Storage: -10°C to 60°C, humidity: 5% to 95%(Non-condensing)

Warranty

As Per Manufacturer Terms and Condition

Other Details

Dimension (CM) - L x W x H

44 x 20 x 4.4

Unit Of Measurement

1 Piece

Weight

2.700 kg

Generic Type

Switches

Manufacturer Details

Grand Stream Connecting The World

28, HAL 3rd stage, Indira Nagar, Bangalore - 560075

Email:[email protected]

Packer Details

Grand Stream Connecting The World

28, HAL 3rd stage, Indira Nagar, Bangalore - 560075

Email:[email protected]

Country Of Origin

India


Grandstream 24-Port Enterprise Layer 2 Managed Network Switch GWN7803
